Fiberglass floor filter paint Stop Filter media for spray booth paint booth air filter
Product introduction:
The fiber glass paint arrestor is an environmental filter with green and white color, the density is increased orderly and the bottom density is the largest. It is able to prevent the short fiber spread, to collect the dissociative particles and to protect the air circulation system and the ceiling filtration systems.
It is mainly used to absorb the over dissociative particles and decrease the pollution.
Specially for sprayed to catch to spray in the paint system of paint fog and stem the dust but design be applicable to an automobile,furniture,machine zero parts the dry type of etc. spray the paint system and car.
Product advantages:
1 Strong flexibility, the anti- split of the glass fiber filter the material fiber to present to pass to increase structure gradually, catching a rate high
2 Can keep shape constant its filtering a fiber have to store paint fog dust.Wear to attach to fix on the material of defend a germ layer.
3 There is the color noodles to enter spirit noodles for the air,Don't contain silicon ketone.
Technical Parameters:
| Model | SAF-50/60 | SAF-100 |
| Average arrestance | 92%-96% | 97%-99% |
| Initial pressure drop | 15Pa | 20Pa |
| Final pressure drop | 250 Pa | 280 Pa |
| Air velocity | 0.7-1.5.m/s | 0.7-1.75.m/s |
| Dust holding at final | 3200-3600g/m2 | 3600-4900g/m2 |
| Temperature resistance | 170°C | 170°C |
| Temperature short peaks | 190°C | 190°C |
| Normal thickness | 50/60mm | 100mm |
| Normal size | 0.8m*20 1.0m*20m 2.0m*20m | 0.8m*20 1.0m*20m 2.0m*20m |
The size can be customized according to customers requirement
